Single Phase Submersible Pump

Description

Single phase submersible pump is used domestically in rural areas, gardens, personal villas, building facilities, and waterfronts. Some specifications of the pump include the output diameter of 1.5 to 2 inches, maximum discharge capacity of 24 cubic meters per hour, maximum height of 263 meters, test pressure of 39 bars, horizontal and vertical installation capability, use of ball bearings, oil cooling and lubrication, stainless steel body and metal part, and the output power of 0.37 to 2.2 kilowatts. The submersible electromotor and pump are coupled according to the NEMA standard and the electromotor is designed according to the IEC 60034 standard.

Applications of single phase submersible pump :

Tis electro pump could be used in the following cases:

1. Domestic applications
2. Rural areas
3. Gardens
4. Personal villas
5. Building facilities
6. Single phase waterfronts

Specifications of the single phase submersible pump :

• Output diameter: 1.5- 2 inches
• Discharge capacity: maximum 24 cubic meters per hour
• Height: maximum 263 meters
• Test pressure: 39 bars
• Installation: both horizontally and vertically
• Ball bearing type
• Oil cooling and lubrication
• body and metal parts made of Stainless steel
• the output power of submersible motors : 0.37 ~2 kilowatts
• submersible electromotor and pump are coupled according to the NEMA standard
• the electromotor is designed according to the IEC 60034 standard
